The CiT 500W ATV E power supply is perfect for powering a home oroffice computer and with an 80 PLUS Bronze efficiency rating whichguarantees to seamlessly deliver full wattage to your PC system. TheATV E power supply housing a 120mm black fan offers both cooling andlow noise.
Offering a straightforward and reliable way to power your system, wewant the ATV E to be that simple with a single +12v rail, active PFCand top tier circuit protections, this PSU is built for purpose and canhandle all your main computing needs, just plug it in and get to work.
The smooth elegant all-black casing and all black cable configurationallows the PSU to fit seamlessly into your PCs theme and supported by atwo-year warranty. The CiT ATV E is the power supply to deliverreliable and affordable power.
Key Features- 80 Plus Certification - The CiT ATV E is 80 PLUS Bronze certifieddelivering up to 85 percent for high efficiency.
- All Black - The all-black PSU casing and cable configuration theATV E effortlessly fits and blends into the rest of your system to adda sleek and stealth finish.
- Wired Power Supply - Flat black cables make it easy to connecteverything together and easily manage and save the space inside thechassis.
- Single 12V Rail Output - Single 12V rail for high compatibilityand extreme high current output.
- Active PFC - CiT have used an active PFC ensures small and lightcomponents with great flexibility and control allowing you to operatein universal input range for an excellent performance.
- Low Noise - The ATV E includes a 12cm black fan providesexcellent cooling and low-noise.
- Hardware Protection - Top tier circuit protections keeps yourbuild running strong and your hardware safe - OVP (Over VoltageProtection), OPP (Over Power Protection) & SCP (Short CircuitProtection).
- Warranty - The CiT ATV E comes with 2 Years Warranty.
PSU SpecificationsAC INPUT: 100-240 VAC 8A 50-60Hz
DC Output +3.3V +5V +12V1 -12V +5VSB
16A 18A 38A 0.3A 2.5A
Total: 500W
Connectors- 20+4 Pin Main Connectors: 1
- 4+4 Pin (8-pin) 12V Connectors: 1
- SATA Connectors: 6
- 4-Pin Molex Connectors: 2
- 6+2 Pin PCI-e Connectors: 2
- Floppy: 1
Detailed Specifications- Dimensions: 150mm x 85mm x 140mm (W x H x D)
- Input Voltage: 100-240 VAC
- Input Current: 8A
- Input Frequency Range: 50-60Hz
- PFC: Active PFC
- Power Good Signal: 100-500ms
- Hold Up Time: Greater than or equal to 10ms
- Efficiency: > 82% (85% max)
- MTBF: 100,000 Hours
- Protection: OVP / OLP / OPP / SCP
- Power: 500W
- Operation Temperature: 0-40°C
- Safety: CE / CCC / CB / UKCA / ROHS
- Cooling: 120mm Black Fan
- Noise: 38dBA
- 80 Plus Certified: Yes - 80 Plus Bronze
