The FX Pro series is the latest PSU series launched by CiT. The FX Pro range are a non-modular power supply that we offer in four power configurations, 400W, 600W, 700W and 800W all are 80 Plus Bronze certified. Not only is this power supply impressive in performance but the components used in this power supply are components normally used by top tier brands. This Power supply is perfect for enthusiastic gamers who are pursuing the ultimate gaming experience. Realise a more powerful performance.
Key Features - 80 Plus Bronze Certification - The FX Pro range are 80 Plus Bronze certified achieving an efficiency of up to 88% at a load of 50%.
- Japanese TK Main Capacitor - With a Japanese TK main capacitor included the FX Pro Range delivers a reliable life expectancy and quality assurance.
- Power - The FX Pro range offers some real power, the 12V output can be rated over 90% of the total level, ensuring a smooth operation. The 80 Plus 230V EU Bronze efficiency enables your high end components to work to their full potential.
- Structure - The structure of a power supply decides the main performance such as the efficiency and temperature but with a double forward and active PFC, the FX Pro range ensures a supreme performance.
- Full Range Voltage Power Off Protection - With a full range voltage and SCP function, if the power is cut off you don’t need to worry, the FX Pro will activate the power off protection function to protect your PSU and motherboard effectively.
- Professional Looking - Black is the colour, with the all black finish and the flat black cables give your gaming PC a clean look. The flat black cables enable builders to easily manage and save space creating a great looking PC.
- Warranty - The FX Pro range comes with 2 years warranty.
PSU SpecificationsAC INPUT: 200-240VAC 6A 47-63HZ
DC Output:
+3.3V +5V +12V1 -12V +5VSB
18A 20A 66A 0.3A 2.5A
Max: 800W
Connectors - 20+4 Pin Main Connectors: 1
- 4+4 Pin 12V Connectors: 2
- SATA Connectors: 6
- 4-Pin Molex Connectors: 2
- 6+2 Pin PCI-e Connectors: 4
Detailed Specifications - Dimensions: 150mm x 85mm x 160mm (W x H x D)
- Input Voltage: 200-240VAC
- Input Current: 6A
- Input Frequency Range: 47-63HZ
- PFC: Active PFC
- Power Good Signal: Approx. 300ms
- Hold Up Time: 10ms
- Efficiency: 85%
- MTBF: 30,000 Hours
- Protection: OVP / UVP / OLP / OPP / SCP
- Power: 800W
- Operation Temperature: 0-40°C
- Safety: CE / CCC
- Cooling: 14cm Cooling Fan
- Noise: 40dBA
- 80 Plus Certified: Yes - 80 Plus Bronze
