Intel Next Unit of Computing Intel Core i5-10210U 10th Gen, 1.6 GHz, 16GB SODIMM RAM, 256GB M.2, Wi-Fi 6 and Bluetooth - Pre Built NUC Form Factor

Intel Next Unit of Computing Intel Core i5-10210U 10th Gen, 1.6 GHz, 16GB SODIMM RAM, 256GB M.2, Wi-Fi - Pre Built NUC Form Factor

Think You Know What Small Can Do? Think Again
Whether you or your customers are home consumers or small businesses, there is an Intel NUC system to meet the needs of value-oriented buyers who need basic functionality at an affordable price?all in a small package that's about 4 inches square.

Where Performance Meets Value
Connect, Consume, Repeat
Featuring the power of 10th Generation Intel Core processors, the Intel NUC 10 Performance has the power to create content as well as consume it.
Record and mix music, add animation effects to your video edits, or over-binge your favourite shows in stunning ultra high-def 4K.
Whatever it is, this Intel Mini PC brings full-size PC performance at a size small enough to fit in the palm of your hand.
Available with a choice of hard drive configurations to meet your speed and storage needs, the NUC 10 Performance has the ports to connect every last peripheral and keep your data moving at top speed.
And with triple display support, you can multitask across multiple screens and give your brilliance room to spread out.

Storage
NETAC NV2000 (NT01NV2000-256-E4X) 256GB NVMe M.2 Interface, PCIe x3, 2280 Length, Read 2500MB/s, Write 1000MB/s (Fitted)
Internal Drive Form Factor:
M.2 and 2.5" Drive
Internal Drives Supported:
2
Card reader: integrated
Compatible memory cards: SDXC

Memory
SODIMM
Patriot Signature Line 16GB No Heatsink (1 x 16GB) DDR4 3200MHz SODIMM System Memory - Fitted

Graphics
Integrated Graphics:
Yes
Graphics Output:
HDMI 2.0b; USB-C (DP1.2)
Displays Supported:
3

Network
Integrated LAN:
Intel Ethernet Connection i219-V
Integrated Wireless:
Intel Wi-Fi 6 AX201
Integrated Bluetooth:
Yes
Consumer Infrared Rx Sensor:
Yes

Ports & interfaces
USB Ports:
7

USB Configuration:
2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); 2x USB 2.0 via internal headers
USB Revision:
2.0, 3.1 Gen2
USB 2.0 Configuration (External + Internal):
0 + 2
USB 3.0 Configuration (External + Internal):
2B 2F + 0
Total SATA Ports:
2
Max SATA 6.0 Gb/s Ports:
2
RAID Configuration:
2.5in HDD/SSD + M.2 SATA SSD (RAID-0 RAID-1)
Audio (back channel + front channel):
7.1 digital (HDMI, Type-C)

Expansion slots
PCI Express Revision:
Gen3
PCI Express Configurations:
M.2 slot with PCIe X4 lanes
Removable Memory Card Slot:
SDXC with UHS-II support
M.2 Card Slot (storage):
22x42/80

Design
Chassis type: UCFF
Product colour: Black
On/off switch: Yes
LED indicators: Yes
Product type: Mini PC barebone

Performance
Lithography:
14 nm
TDP:
25 W
DC Input Voltage Supported:
19 VDC
Processor Included:
Intel Core i5-10210U Processor (6M Cache, up to 4.20 GHz)
Intel vPro Platform Eligibility:
No
Total Cores:
4
Total Threads:
8
Processor Base Frequency:
1.60 GHz
Max Turbo Frequency:
4.20 GHz

Power
Bundled with UK Mains to Clover C5 5 Amp 1.8m Black OEM Power Cable

Weight & dimensions
Width: 115 mm
Depth: 111 mm
Height: 51 mm
